TAKET
BATPURE Tiny Super Tweeter set

Easy to install, parallel connect with existing speaker terminal.
Quite fast, three dimensionally, spacious soundstage and with a good depth, overall it becomes lively.

Three way speaker system which have good sound. The vagueness of sound becomes clearly, if BATPURE was added there, and also the depth of sound field is improved.
TV built-in speakers. BATPURE is connected with TV speakers. It recommend soldering the connector of BATPURE and speaker terminal. The clip substitutes with the switch in the photo. for the experiment. Even if BATPURE is built-in the TV instead of outside, effect is fine.

In the Super-tweeter, TAKET cuts the frequency response under 20kHz as much as possible. First of all, frequency response under 20kHz is physically cut by adjusting the pitch and the depth of the wave of the vibration board film. This is possible because of the Heil-like structure. In addition a low frequency region is cut electrically by a capacitor. Thus, the SPL under 20kHz of the main speaker system is not changed, even if the TAKET Super-tweeter is added. It approaches an ideal super-tweeter that adds only to the sound over 20kHz.
TAKET super tweeter has especial characteristic that we cut the sound of under 20kHz ( which you can listen the sound ) as much as possible to design ideal super tweeter.
So, it is very difficult to listen the sound from TakeT super tweeter, if it is connected to main speaker. It is the big difference from other super tweeters.

Maximum rate	150V
Impedance	Infinity~4Kohms(DC~100kH)
Frequency response range	20kHz~150kHz
Efficiency	70dB/1m
Dimensions	30x23x3.8mm
Weight	1g
